Products Description
High hardness /silicon /heavy metal industrial wastewater makes nanofiltration,reverse osmosis, electrodialysis, and evaporators face the risk of fouling.The traditional softening process currently on the market is: dosing PAC,PAM,NaOH,Na2CO3, NaAlO2, and other agents. Then it is treated by sedimentation tank,sand filter and hollow fiber membrane. In contrast, the new treatment process based on PEK tubular membrane only dosing NaOH and Na2CO3, without PAC or PAM,product water hardness ≤ 50mg/L, total silicon ≤ 20 mg/L.
Product Paramenters
| MEMBRANE MATERIAL | PVDF | PEK | |||||
Unit | Pore size/MWCO | ||||||
| 0.2μm | 30nm | 0.2μm | 50nm | 35nm | 10nm | ||
| Pure water flux | LMH,100 kPa | 1500 | 900 | 2500 | 1200 | 700 | 300 |
Operating pressure | kPa | -500~800 | -100~1000 | ||||
Maximum Operating Tempreature | ℃ | 65 | 65 | ||||
Operating pH range | 2~10 | 0~14 | |||||
Chlorine resistance | ppm▪h | 250000 | 300000 |
Operation Specifications
Clean water flux 100kpa: 2500LMH(0.2um),1500LMH（50nm）1200LMH(30nm), 300LMH(10nm)
Typical Operation Pressure: 3.0-5.0 bar
Max.Operation Pressure: 116 psi (8.0 bar)
Max.Operation Temperature (pH:8): 149°F (65℃)
pH-Continuous Operation @25℃: 0~14 Max.
Chlorine Exposure: 300,000ppm·h
Process flow chart
Features
Design flux
In External MBR = 50~120L/h·m2
In Air lift MBR= 30~50L/h·m2
In RO brine softening = 100~300L/h·m2
Circulation pump flow design
| Model | Tube Diameter(mm) | Tube number（pcs） | Circulation flow(m³/h) |
| PL-G-638 | 6 | 655 | 65×V |
| PL-G-838 | 8 | 365 | 69×V |
| PL-G-636 | 6 | 359 | 36×V |
| PL-G-836 | 8 | 210 | 37×V |
| PL-G-634 | 6 | 163 | 16×V |
| PL-G-834 | 8 | 91 | 16×V |
Specifications
| Model | Module quantity | Module area (m2) | Installed power (kw) | Processing capacity （m3/h） | Circulation pump parameters |
| PL-G-836-P | 4 | 60 | 15 | 70 | 160m3/h,32m |
| PL-G-836-P | 8 | 120 | 30 | 140 | 160m3/h,32m |
| PL-G-836-P | 6 | 90 | 18.5 | 100 | 160m3/h,48m |
| PL-G-836-P | 12 | 180 | 37 | 200 | 160m3/h,48m |
| PL-G-838-P | 4 | 112 | 45 | 130 | 280m3/h,32m |
| PL-G-838-P | 8 | 224 | 90 | 260 | 280m3/h,32m |
| PL-G-838-P | 6 | 168 | 55 | 200 | 280m3/h,48m |
| PL-G-838-P | 12 | 336 | 110 | 400 | 280m3/h,48m |
