The maximum table travel distances are 5000 mm in the X direction, 3500 mm in the Y direction, and 1000 mm in the Z direction.
The GS1215 uses a BT50 spindle taper, which is suitable for heavy-duty machining tasks.
The spindle speed range for the GS1215 is from 10 to 8000 r.p.m.
The maximum table load capacity of the GS1215 is 22000 kg.
The GS1215 offers a positioning accuracy of 0.01 mm.
The GS1215 operates on 5 axes, allowing for complex machining operations.
The GS1215 weighs approximately 85000 kg.
The GS1215 can operate on voltages of 220V, 380V, or 415V.
The GS1215 is suitable for various industries including aerospace component manufacturing, automotive part production, tool and die making, and heavy machinery fabrication.
The GS1215 has a maximum cutting length capability of 3000 mm.
The spindle motor power for the GS1215 ranges from 15 kW to 30 kW.
The GS1215 is packaged in a standard export package, customized according to customer requirements.
The repeatability of the GS1215 is 0.01 mm in the X, Y, and Z axes.
The supply ability for the GS1215 is 100 sets per month.
The table size of the GS1215 is 3000 mm by 1600 mm.
