Growatt Hybrid Inverter 5kw 10 KW Solar Power System Connect Generator and Wind Turbine On Pitched Roof
Growatt Hybrid Inverter 5kw 10 KW Solar Power System Connect Generator and Wind Turbine On Pitched Roof
Growatt Hybrid Inverter 5kw 10 KW Solar Power System Connect Generator and Wind Turbine On Pitched Roof
Growatt Hybrid Inverter 5kw 10 KW Solar Power System Connect Generator and Wind Turbine On Pitched Roof
Growatt Hybrid Inverter 5kw 10 KW Solar Power System Connect Generator and Wind Turbine On Pitched Roof
Growatt Hybrid Inverter 5kw 10 KW Solar Power System Connect Generator and Wind Turbine On Pitched Roof

0 Customer Reviews

Add To Wishlist Share to Social




Hybrid solar inverters have function of both on grid inverters and off grid inverters,so hybrid solar system have the advantage of on grid and off grid solar system, all equipment are connected to hybrid solar inverter,so the hybrid inverter is the most important device for the system. Hybrid Inverter

Hybrid Storage Solar System

Product Specification

DatasheetSPH3000SPH3600SPH4000SPH4600SPH5000SPH6000
DC input data
Max. recommended PV power6600W6600W6600W8000W8000W8000W
Start voltage150V
Max. PV voltage550V
PV voltage range120V-550V
MPPT voltage range
/nominal voltage		150V-550V /360V
Max. input current of tracker A/B12A/12A
Number of MPP trackers / strings per MPP tracker2/1
AC Output
Rated AC output power3000W3680W4000W4600W4999W6000W
Max. AC apparent power3000VA3680VA4000VA4600VA5000VA6000VA
Max. output current16A16A22A22A22A27A
Nominal AC output voltage230V
Nominal grid frequency50/60Hz
Power factor at rated power1
THDI<3%
AC output power(Backup)
Max. output power3000W
Rated AC output voltage230Vac
Rated AC output frequency50/60Hz
Automatic switchover time<0.5S
Battery data
Battery voltage range42~59V
Max. charging voltage58V
Max charging and discharging
current		66A
Max charging and discharging
power		3000W
Battery typelithium /Lead-acid
Deep of discharging80%DOD/50%DOD
Capacity of battery3~12kWh
Efficiency
Max. efficiency97.5%97.5%97.5%97.6%97.6%97.7%
Euro European efficiency97.0%97.0%97.0%97.1%97.1%97.1%
MPPT efficiency99.5%
Protection devices
DC switchyes
DC reverse polarity protectionyes
Battery reverse protectionyes
Output over current protectionyes
Output over voltage protectionyes
Ground fault monitoringyes
Grid monitoringyes
Integrated all - pole sensitive
leakage		yes

AC-coupled solutions





Single phase AC-coupled inverter basic application

Single phase all-in-one hybrid inverter ideal for home systems. stunning IP65 protection level, more durable and flexible for installation; multiple programmable working modes, decide by yourself how to realize self sufficiency and make the max out of your system; the EPS output can even provide backup supply during grid absence;comprehensive accessories including battery, meter and data logger optional for different application scenarios.
