CNC Plasma Cutting Machine
The CNC Plasma Cutting Machine offers a cost-effective and high-precision solution for cutting various metals, including iron, steel, aluminum, galvanized sheets, and titanium plates. Designed with advanced features for smooth operation and high productivity, this machine is ideal for industries such as automotive, shipbuilding, advertising, and general manufacturing.
Key Features:
- Light Structural Design: The beam features a lightweight yet rigid structure, ensuring good stability and reduced deadweight for easy handling.
- Dual-Motor Dual-Driven System: The Y-axis uses a dual-motor, dual-driven system, while all axes (X, Y, Z) employ dual-straight rails for smooth, high-precision driving.
- High Cutting Accuracy: Designed for cutting three-dimensional LED characters, metal panels, and floor cutting, it achieves high accuracy. When paired with a USA Hypertherm plasma source, it meets industry-leading standards.
- Efficient Operation: The cutting process results in a small, tidy cutting mouth, reducing the need for secondary dressing or processing.
- Multi-Industry Use: Suitable for a variety of industries, including car manufacturing, pressure vessels, nuclear industries, steel structures, and advertising sign production.
Technical Specifications:
- Model: 1530, 1325 Plasma Cutting Machine
- Working Area: 1500mm x 3000mm or 1300mm x 2500mm
- Material: Works with iron, steel, aluminum sheets, galvanized sheets, and titanium plates.
- Thickness: Capable of cutting materials ranging from 0.5mm to 19mm.
- Cutting Speed: Up to 6000mm/min for efficient operation.
- Power: 8.5kW
- Input Voltage: 380V, 50HZ (customizable per requirements).
- Plasma Current: Available in 63A, 100A, 120A, 160A, and 200A options.
- Cutting Mode: Features untouched arc striking for precise cuts.
- Cooling System: Includes water pump and tank for circulating water cooling.
- Z-Axis Travel: 0-70mm with an automatic elastic raise of 0-5mm.
- Rail Guide: Uses precision round rails for smooth operation.
- Transmission: Equipped with Taiwan imported ball screws for high accuracy.
- Operation Language: English (optional).
- Command Types: Supports G-code, *.uoo, *.mmg, and *.plt formats.
- Optional Power Source: USA brand Hypertherm for high-performance cutting.
- Spare Parts: Includes electrode, electric nozzle, and water jacket.
Applications:
- Automotive: Precision cutting for car parts, motorcycle frames, and other vehicle components.
- Shipbuilding: Cutting metal plates for ship construction and repair.
- Engineering & Construction: Fabricating steel structures and machinery.
- Advertising: Creating logos, decorative signs, and promotional materials from various metal types.
- General Manufacturing: Ideal for various metal cutting needs across different industries.
This CNC Plasma Cutting Machine delivers high precision, efficiency, and cost-effectiveness, making it a valuable asset in a wide range of industrial applications.
| 1) The beam uses light structural design,with good rigidity structure, light deadweight . |
| 2) The gantry structure, Y axis used dual-motor dual-driven system,X,Y,Z axis all use dual-straight rail that make the machine driving smoothly with high-precision. |
| 3) Aiming at cutting three dimension LED character, trough metal panels and floor cutting, the accuracy can reach good indicators.If it equipped with United States HYPERTHERM plasma source the machine can reach threshold. |
| 4) Equipped with other advertise equipment (blister/engraving machine) .Improve the efficiency of several times |
| 5) Cutting mouth is small, tidy,and avoid a second dressing processing. |
| Model | 1530 1325 plasma cutting machine |
| Working area (X-Y) | 1500mmx3000mm or 1300*2500mm cnc plasma |
| Working material | Iron, Steel, Aluminum sheets, Galvanized sheets, Titanium Plates |
| Working Thickness | 0.5-19 mm |
| Cutting Speed | 0-6000mm/min |
| Power | 8.5kw |
| Input Voltage | 380V 50HZ (or according to your need) |
| Plasma Current | 63A/100A/120A/160A/200A |
| Connecting Way | USB |
| Working Mode | Untouched arc striking |
| Cooling method | With water pump and tank provide circulating water cooling |
| Z axis travel | 0-70mm |
| The automatic elastic raise | 0-5mm |
| Rail guide | Precision work round |
| Transmit way | Taiwan imported ball screw |
| Operation language | English (Option) |
| Command | G code, *uoo, *mmg, *plt |
| Optional power source | USA brand Hypertherm |
| Spare parts | Electrode ,Electricity nozzle and Water jacket |
