The BZ-150 is a new, efficient, and multi-functional portable water well drilling rig designed for well drilling in soil layers. Its compact structure makes it ideal for use in indoor, courtyard, and narrow site drilling.
Key Features:
Efficient & Versatile: Suitable for drilling in soil, sand, and layers with a few pebbles.
Compact Design: Ideal for confined spaces such as courtyards or indoor areas.
Portable & Lightweight: Easy to transport and operate, weighing only 300kg.
Technical Parameters:
Specification
Details
Drilling Depth
130m
Drilling Diameter
Φ50-450mm
Drill Rod Diameter
Φ50mm
Drill Rod Length
1500mm
Stroke
1500mm
Spindle Speed
90RPM
Max. Feed Force
10KN
Max. Lift Force
10KN
Max. Torque
2000Nm
Water Pump Flow
40L/min
Water Pump Lift Stroke
50m
Diesel Engine Power
16KW
Diesel Engine Speed
2200RPM
Dimensions (L×W×H)
Transport State: 800×800×1700mm
Working State: 800×800×2600mm
Weight
300KG
Suitable Stratum Layer
Soil, Sand, Few Pebbles
