27KW 7000A energy storage lithium battery cell welding point machine
- Section : Machinery
- Category : Welding Equipment
- SKU : 1600972489793
HT-SW33A Spot Welder
The HT-SW33A Spot Welder is a high-performance welding machine specially designed for welding between iron-nickel materials and stainless steel materials. It is ideal for applications such as the welding of ternary batteries with iron-nickel and pure nickel materials. This machine is designed to ensure precise, reliable welds with minimal risk of damaging components.
General Precautions:
Designed for Specific Welding Tasks: The machine is specially designed for welding between iron-nickel materials and stainless steel, especially for ternary battery welding with nickel and pure nickel.
Avoid Short Circuits: It is crucial to ensure that the welding needles are only pressed on one pole connection (either nickel, aluminum, or copper) of the battery. Simultaneously pressing both poles may cause a short circuit, damaging both the battery and the welding machine.
Welding Needle Adjustment: Ensure the distance between the unpressed welding needle and the connecting workpiece is within 5-8mm. Only begin welding once the welding needle can be properly pressed onto the workpiece.
Start with Low Energy: During initial debugging of welding parameters, gradually increase the pulse energy to avoid blackening, splashing, and accelerated pin loss.
Red Laser Caution: The red laser emitted by the welding mechanism should not be directly observed to avoid eye injury.
Safety Warning: The machine contains high-voltage components, so do not attempt to dismantle the shell to avoid safety hazards.
Ventilation Requirements: The machine must be used in a well-ventilated area, and the heat dissipation window must remain unobstructed.
Air Pressure Limits: Do not exceed an air pressure input of 6 kg/cm² (0.6 MPa).
Notice:
- External Air Source: Connect the machine to an external air compressor for operation.
Model Selection:
| Feature | HT-SW33A | HT-SW33A++ |
|---|---|---|
| Output Power | 27KW | 42KW |
| Output Current | 4500A | 7000A |
| Power Supply | AC 220V | AC 220V |
| Output Voltage | 5.6V-6.0V (DC) | 5.6V-6.0V (DC) |
| Peak Welding Energy | 540J (Max.) | 840J (Max.) |
| Charge Current Display | 10A-20A | 10A-20A |
| Pulse Time | 20ms | 20ms |
| Energy Grade | 0-99T (0.2m/T) | 0-99T (0.2m/T) |
| Copper to Copper (with flux) | 0.15-0.3mm | 0.15-0.5mm |
| Pure Nickel to Aluminium | 0.1-0.2mm | 0.15-0.4mm |
| Nickel-Aluminium Composite Sheet to Aluminium | 0.1-0.3mm | 0.15-0.5mm |
| Welding Principles | DC energy storage super farad capacitor | DC energy storage super farad capacitor |
| Trigger Mode | Foot pedal pneumatic trigger | Foot pedal pneumatic trigger |
| Welding Mode | Pneumatic press down spot welding head | Pneumatic press down spot welding head |
| Charging Time | ≤ 18 mins | ≤ 18 mins |
| Dimensions (cm) | 50.51934 | 50.51934 |
| Net Weight (kg) | 16.7kg | 16.7kg |
This HT-SW33A Spot Welder is an essential tool for efficient and safe welding in battery manufacturing and other related industries.
