The maximum vertical conveying distance is 150 meters.
The maximum horizontal conveying distance is 400 meters.
The productivity rate is 40 cubic meters per hour (40M³/H).
The weight of the trailer is 3200 kg.
The maximum delivery pressure is 10 MPa.
The main motor power is 45 kW.
The maximum aggregate size is 30 mm.
The concrete pump can be controlled using a control box and wired remote control.
It has CE, CCC, and ISO certifications.
Key features include high operating efficiency, a powerful electric motor, compact design for easy transport, and durable construction.
It is suitable for construction sites, road and bridge projects, high-rise buildings, concrete repairs, and large-scale concrete pouring tasks.
Yes, the compact design makes the concrete pump trailer easy to transport.
Yes, it can be used for both residential and commercial construction projects.
The feeding height is 1400 mm.
Routine maintenance is recommended to ensure optimal performance, but there are no special requirements.
